-30℃~50℃ HEAT AND COOLING CHILLER
Features and functions of the unit:
XYJR series hot and cold temperature control machine is launched by XIEYI company to meet the needs of customers. It is a dual-purpose machine that provides cooling and heating circulating water. It is widely used in sponge manufacturing, sauna swimming pool, composite material foaming, medicine, and the Chemical Industry.
Model | XYJR-1000 | XYJR-1500 | XYJR-2000 | XYJR-2500 |
Cooling capacity(-15°C/KW) | 24 | 30 | 50 | 60 |
Compressor input power(HP) | 15HP*2 | 20HP*2 | 30HP*2 | 40HP*2 |
Refrigeration temperature (°C) | ≤-40°C | ≤-40°C | ≤-40°C | ≤-40°C |
Heating temperature (°C) | 30 | 30 | 30 | 30 |
Heating power (KW) | 48KW | 60KW | 72KW | 80KW |
Circulation pump flow (m³/H) | 25 | 25 | 25 | 25 |
Circulation pump power (KW) | 4 | 5.5 | 7.5 | 7.5 |
Maximum lift (m) | 30 | 36 | 48 | 48 |
Safety protection | Overvoltage, overvoltage, phase loss, refrigeration system high and low pressure protection, flow protection | |||
Control appliances | Siemens PLC | |||
Communication Interface | Default Modbus, other customized | |||
Refrigerant type | R404A | R404A | R404A | R404A |
Brine | Environmental protection rust inhibitor | |||
Brine inlet and outlet interface | G 1.2" | G 1.5" | G2" | G2" |
Cooling water inlet and outlet interface | G 1.2" | G 1.5" | G2" | G2" |
Cooling method | Water cooling/air cooling | |||
Weight (Kg) | 1000 | 1350 | 1450 | 2500 |
Dimensions mm (L*W*H) | 1500*1300*1800 | 1600*1400*2000 | 1600*1400*2000 | 2500*1600*2300 |
Note:
1. Cooling capacity is based on: chilled water inlet and outlet temperature 17°C/12°C; cooling inlet and outlet air temperature 30°C/40°C.
2. Working range: circulating water temperature range: 5°C to 50°C; temperature difference between inlet and outlet water is 3°C to 8°C.
The working environment temperature should be ≤35ºC.
3. The company reserves the right to change the above parameters or dimensions without prior notice.
If you have special requirements, please customize them in advance.
